Suggested Radiographs

Applying basic principles of radiography and fundamental knowledge of upper extremity orthopaedics, an outline of recommended radiographs for different clinical problems may be provided as follows.

Clinical Diagnosis

Recommended Radiographs

Glenohumeral Joint Imaging
Subacromial impingement, bursitis Shoulder impingement series
Rotator cuff tendinitis, tear Shoulder impingement series
Acute glenohumeral dislocation Shoulder trauma series
Glenohumeral arthritis Shoulder trauma series
Postop shoulder replacement Shoulder trauma series
Proximal humerus fracture Shoulder trauma series
Chronic glenohumeral subluxation Shoulder instability series
Shoulder pain in throwing athlete Shoulder instability series
Clavicle Imaging
Mid-shaft clavicle fracture Clavicle series
Clavicle nonunion Clavicle series
Distal third clavicle fracture ACJ AP view, axillary lateral
Acromioclavicular arthritis ACJ AP view, axillary lateral
Acromioclavicular dislocation ACJ AP view w/comparison view
Medial third clavicle fracture Serendipity view
Sternoclavicular arthritis Serendipity view
Sternoclavicular dislocation Serendipity view
Elbow Imaging
Lateral or medial epicondylitis Elbow AP, lateral views
Elbow trauma, fractures Elbow AP, lateral views
Radial head fracture Elbow AP, lateral, radial head views
Elbow arthritis Elbow AP, lateral views
Distal biceps rupture Elbow AP, lateral views
Elbow pain in throwing athlete Elbow AP, lateral views


We hope that this review of upper extremity musculoskeletal imaging has been useful.  Please direct comments or questions about this review to me at the office 316-631-1600.  Comments only (no questions please) may be emailed to my office by clicking on the link on the bottom of this page.


1.  Berquist TH.  Diagnostic Imaging of the Elbow (Ch. 6) in The Elbow and Its Disorders, 3rd edition, Morrey BF (ed).  Philadelphia:  WB Saunders Co., 2000.

2.  Bindra RR, Evanoff BA, Chough LY, Cole RJ, Chow CJY, Gelberman RH.  The use of routine wrist radiography in the evaluation of patients with carpal tunnel syndrome.  J Hand Surg, 22A(1): 115-9, 1997.

3.  Duralde XA, Gauntt SJ.  Troubleshooting the supraspinatus outlet view.  J  Shoulder Elbow Surg, 8(4): 314-319, 1999.

4.  Friedman RJ, Hawthorne KB, Genez BM.  The use of computerized tomography in the measurement of glenoid version.  J Bone Joint Surg, 74(A): 1032-1037, 1992.

5.  Giuffre BM and Moss MJ.  Optimal Positioning for MRI of the Distal Biceps Brachii Tendon:  Flexed Abducted Supinated View.  Am J Roentgenology, 182: 944-946, 2004.

6.  Howson MP and Kerrigan CL.  Handy Views:  Radiographic Positioning of the Hand and Wrist.  Philadelphia:  Lippincott-Raven, 1998.

7. Ono K, Yamamuro T, Rockwood CA Jr.  Use of a thirty-degree caudal tilt radiograph in the shoulder impingement syndrome.  J Shoulder Elbow Surg, 1(5): 246-252, 1992.

8.  Rockwood CA Jr and Jensen KL.  X-Ray Evaluation of Shoulder Problems (Ch. 5) in The Shoulder, 2nd edition, Rockwood and Matsen (eds).  Philadelphia:  WB Saunders Co., 1998.

9.  Yin Y, Mann FA, Gilula LA.  Positions and Techniques (Ch. 5) in Imaging of the Wrist and Hand, Gilula and Yin (eds).  Philadelphia:  WB Saunders Co., 1996.

10.  Zlatkin MB (ed).  MRI of the Shoulder, 2nd edition.  Philadelphia:  Lippincott Williams & Wilkins, 2003.
